Every company, regardless of its size, wants to deliver the best products and services to its customers. To achieve this, companies want to understand industry trends and customer behavior, and optimize internal processes and data analyses on a routine basis. This is a crucial component of a company’s success.

A very prominent part of the analyst role includes business metrics visualization (like sales revenue) and prediction of future events (like increase in demand) to make data-driven business decisions. To approach this first challenge, you can use Amazon QuickSight, a cloud-scale business intelligence (BI) service that provides easy-to-understand insights and gives decision-makers the opportunity to explore and interpret information in an interactive visual environment. For the second task, you can use Amazon SageMaker Canvas, a cloud service that expands access to machine learning (ML) by providing business analysts with a visual point-and-click interface that allows you to generate accurate ML predictions on your own.

When looking at these metrics, business analysts often identify patterns in customer behavior, in order to determine whether the company risks losing the customer. This problem is called customer churn, and ML models have a proven track record of predicting such customers with high accuracy (for an example, see Elula’s AI Solutions Help Banks Improve Customer Retention).

Building ML models can be a tricky process because it requires an expert team to manage the data preparation and ML model training. However, with Canvas, you can do that without any special knowledge and with zero lines of code. For more information, check out Predict customer churn with no-code machine learning using Amazon SageMaker Canvas.

In this post, we show you how to visualize the predictions generated from Canvas in a QuickSight dashboard, enabling intelligent decision-making via ML.

Overview of solution

In the post Predict customer churn with no-code machine learning using Amazon SageMaker Canvas, we assumed the role of a business analyst in the marketing department of a mobile phone operator, and we successfully created an ML model to identify customers with potential risk of churn. Thanks to the predictions generated by our model, we now want to make an analysis of a potential financial outcome to make data-driven business decisions about potential promotions for these clients and regions.

The architecture that will help us achieve this is shown in the following diagram.

The workflow steps are as follows:

1. Upload a new dataset with the current customer population into Canvas.
2. Run a batch prediction and download the results.
3. Upload the files into QuickSight to create or update visualizations.

You can perform these steps in Canvas without writing a single line of code. For the full list of supported data sources, refer to Importing data in Amazon SageMaker Canvas.

Prerequisites

For this walkthrough, make sure that the following prerequisites are met:

• Run through the solution in Predict customer churn with no-code machine learning using Amazon SageMaker Canvas. Make sure that, during the model building phase, you don’t drop the State and Phone attributes. You use these later.
• Sign up for a QuickSight subscription. For this post, we only use QuickSight features included in the Standard subscription.

Use the customer churn model

After you complete the prerequisites, you should have a model trained on historical data in Canvas, ready to be used with new customer data to predict customer churn, which you can then use in QuickSight.

1. Create a new file churn-no-labels.csv by randomly selecting 1,500 lines from the original dataset churn.csv and removing the Churn? column.

We use this new dataset to generate predictions.

We complete the next steps in Canvas. You can open Canvas via the AWS Management Console, or via the SSO application provided by your cloud administrator. If you’re not sure how to access Canvas, refer to Getting started with using Amazon SageMaker Canvas.

2. On the Canvas console, choose Datasets in the navigation pane.
3. Choose Import.

4. Choose Upload and choose the churn-no-labels.csv file that you created.
5. Choose Import data.

The data import process time depends on the size of the file. In our case, it should be around 10 seconds. When it’s complete, we can see the dataset is in Ready status.

6. To preview the first 100 rows of the dataset, choose the options menu (three dots) and choose Preview.

7. Choose Models in the navigation pane, then choose the churn model you created as part of the prerequisites.

8. On the Predict tab, choose Select dataset.

9. Select the churn-no-labels.csv dataset, then choose Generate predictions.

Inference time depends on model complexity and dataset size; in our case, it takes around 10 seconds. When the job is finished, it changes its status to Ready and we can download the results.

10. Choose the options menu (three dots), Download, and Download all values.

Optionally, we can take a quick look at the results choosing Preview. The first two columns are predictions from the model.

We have successfully used our model to predict churn risk for our current customer population. Now we’re ready to visualize business metrics based on our predictions.

Import data to QuickSight

As we discussed previously, business analysts require predictions to be visualized together with business metrics in order to make data-driven business decisions. To do that, we use QuickSight, which provides easy-to-understand insights and gives decision-makers the opportunity to explore and interpret information in an interactive visual environment. With QuickSight, we can build visualizations like graphs and charts in seconds with a simple drag-and-drop interface. In this post, we build several visualizations to better understand business risks and how we could manage them, such as where we should launch new marketing campaigns.

To get started, complete the following steps:

1. On the QuickSight console, choose Datasets in the navigation pane.
2. Choose New dataset.

QuickSight supports many data sources. In this post, we use a local file, the one we previously generated in Canvas, as our source data.

3. Choose Upload a file.

4. Choose the recently downloaded file with predictions.

QuickSight uploads and analyzes the file.

5. Check that everything is as expected in the preview, then choose Next.

6. Choose Visualize.

The data is now successfully imported and we’re ready to analyze it.

Create a dashboard with business metrics of churn predictions

It’s time to analyze our data and make a clear and easy-to-use dashboard that recaps all the information necessary for data-driven business decisions. This type of dashboard is an important tool in the arsenal of a business analysts.

The following is an example dashboard that can help identify and act on the risk of customer churn.

On this dashboard, we visualize several important business metrics:

• Customers likely to churn – The left donut chart represents the number and percent of users over 50% risk of churning. This chart helps us quickly understand the size of a potential problem.
• Potential revenue loss – The top middle donut chart represents the amount of revenue loss from users over 50% risk of churning. This chart helps us quickly understand the size of potential revenue loss from churn. The chart also shows that we could lose several above-average customers as a percent of potential revenue lost that’s bigger than the percent of users at risk of churning.
• Potential revenue loss by state – The top right horizontal bar chart represents the size of revenue lost versus revenue from customers not at risk of churning. This visual could help us understand which state is the most important for us from a marketing campaign perspective.
• Details about customers at risk of churning – The bottom left table contains details about all our customers. This table could be helpful if we want to quickly look at the details of several customers with and without churn risk.

Customers likely to churn

We start by building a chart with customers at risk of churning.

1. Under Fields list, choose the Churn? attribute.

QuickSight automatically builds a visualization.

Although the bar plot is a common visualization to understand data distribution, we prefer to use a donut chart. We can change this visual by changing its properties.

2. Choose the donut chart icon under Visual types.
3. Choose the current name (double-click) and change it to Customers likely to churn.

4. To customize other visual effects (remove legend, add values, change font size), choose the pencil icon and make your changes.

As shown in the following screenshot, we increased the area of the donut, as well as added some extra information in the labels.

Potential revenue loss

Another important metric to consider when calculating the business impact of customer churn is potential revenue loss. This is an important metric because it helps us understand the business impact from customers not at risk of churning. In the telecom industry, for example, we could have many inactive clients who have a high risk of churn and but zero revenue. This chart can help us understand if we’re in a such situation or not. To add this metric to our dashboard, we create a custom calculated field by providing the mathematical formula for computing potential revenue loss, then visualize it as another donut chart.

1. On the Add menu, choose Add calculated field.

2. Name the field Total charges.
3. Enter the formula {Day Charge}+{Eve Charge}+{Intl Charge}+{Night Charge}.
4. Choose Save.

5. On the Add menu, choose Add visual.

6. Under Visual types, choose the donut chart icon.
7. Under Fields list, drag Churn? to Group/Color.
8. Drag Total charges to Value.
9. On the Value menu, choose Show as and choose Currency.
10. Choose the pencil icon to customize other visual effects (remove legend, add values, change font size).

At this moment, our dashboard has two visualizations.

We can already observe that in total we could lose 18% (270) customers, which equals 24% ($6,280) in revenue. Let’s explore further by analyzing potential revenue loss at the state level.

Potential revenue loss by state

To visualize potential revenue loss by state, let’s add a horizontal bar graph.

1. On the Add menu, choose Add visual.

2. Under Visual types¸ choose the horizontal bar chart icon.
3. Under Fields list¸ drag Churn? to Group/Color.
4. Drag Total charges to Value.
5. On the Value menu, choose Show as and Currency.
6. Drag Stage to Y axis.
7. Choose the pencil icon to customize other visual effects (remove legend, add values, change font size).

8. We can also sort our new visual by choosing Total charges at the bottom and choosing Descending.

This visual could help us understand which state is the most important from a marketing campaign perspective. For example, in Hawaii, we could potentially lose half our revenue ($253,000) while in Washington, this value is less than 10% ($52,000). We can also see that in Arizona, we risk losing almost every customer.

Details about customers at risk of churning

Let’s build a table with details about customers at risk of churning.

1. On the Add menu, choose Add visual.

2. Under Visual types, choose the table icon.
3. Under Field lists, drag Phone, State, Int’l Plan, Vmail Plan, Churn?, and Account Length to Group by.
4. Drag probability to Value.
5. On the Value menu, choose Show as and Percent.

Customize your dashboard

QuickSight offers several options to customize your dashboard, such as the following.

1. To add a name, on the Add menu, choose Add title.

2. Enter a title (for this post, we rename our dashboard Churn analysis).

3. To resize your visuals, choose the bottom right corner of the chart and drag to the desired size.
4. To move a visual, choose the top center of the chart and drag it to a new location.
5. To change the theme, choose Themes in the navigation pane.
6. Choose your new theme (for example, Midnight), and choose Apply.

Publish your dashboard

A dashboard is a read-only snapshot of an analysis that you can share with other QuickSight users for reporting purposes. Your dashboard preserves the configuration of the analysis at the time you publish it, including such things as filtering, parameters, controls, and sort order. The data used for the analysis isn’t captured as part of the dashboard. When you view the dashboard, it reflects the current data in the datasets used by the analysis.

To publish your dashboard, complete the following steps:

1. On the Share menu, choose Publish dashboard.

2. Enter a name for your dashboard.
3. Choose Publish dashboard.

Congratulations, you have successfully created a churn analysis dashboard.

Update your dashboard with a new prediction

As the model evolves and we generate new data from the business, we might need to update this dashboard with new information. Complete the following steps:

1. Create a new file churn-no-labels-updated.csv by randomly selecting another 1,500 lines from the original dataset churn.csv and removing the Churn? column.

We use this new dataset to generate new predictions.

2. Repeat the steps from the Use the customer churn model section of this post to get predictions for the new dataset, and download the new file.
3. On the QuickSight console, choose Datasets in the navigation pane.
4. Choose the dataset we created.

5. Choose Edit dataset.

6. On the drop-down menu, choose Update file.

7. Choose Upload file.

8. Choose the recently downloaded file with the predictions.
9. Review the preview, then choose Confirm file update.

After the “File updated successfully” message appears, we can see that file name has also changed.

10. Choose Save & publish.

11. When the “Saved and published successfully” message apears, you can go back to the main menu by choosing the QuickSight logo in the left upper corner.

12. Choose Dashboards in the navigation pane and choose the dashboard we created before.

You should see your dashboard with the updated values.

We have just updated our QuickSight dashboard with the most recent predictions from Canvas.

Clean up

To avoid future charges, log out from Canvas.

Conclusion

In this post, we used an ML model from Canvas to predict customers at risk of churning and built a dashboard with insightful visualizations to help us make data-driven business decisions. We did so without writing a single line of code thanks to user-friendly interfaces and clear visualizations. This enables business analysts to be agile in building ML models, and perform analyses and extract insights in complete autonomy from data science teams.

To learn more about using Canvas, see Build, Share, Deploy: how business analysts and data scientists achieve faster time-to-market using no-code ML and Amazon SageMaker Canvas. For more information about creating ML models with a no-code solution, see Announcing Amazon SageMaker Canvas – a Visual, No Code Machine Learning Capability for Business Analysts. To learn more about the latest QuickSight features and best practices, see AWS Big Data Blog.

About the Author

Aleksandr Patrushev is AI/ML Specialist Solutions Architect at AWS, based in Luxembourg. He is passionate about the cloud and machine learning, and the way they could change the world. Outside work, he enjoys hiking, sports, and spending time with his family.

Davide Gallitelli is a Specialist Solutions Architect for AI/ML in the EMEA region. He is based in Brussels and works closely with customers throughout Benelux. He has been a developer since he was very young, starting to code at the age of 7. He started learning AI/ML at university, and has fallen in love with it since then.

Read More

Amazon SageMaker Autopilot has added a new training mode that supports model ensembling powered by AutoGluon. Ensemble training mode in Autopilot trains several base models and combines their predictions using model stacking. For datasets less than 100 MB, ensemble training mode builds machine learning (ML) models with high accuracy quickly—up to eight times faster than hyperparameter optimization (HPO) training mode with 250 trials, and up to 5.8 times faster than HPO training mode with 100 trials. It supports a wide range of algorithms, including LightGBM, CatBoost, XGBoost, Random Forest, Extra Trees, linear models, and neural networks based on PyTorch and FastAI.

How AutoGluon builds ensemble models

AutoGluon-Tabular (AGT) is a popular open-source AutoML framework that trains highly accurate ML models on tabular datasets. Unlike existing AutoML frameworks, which primarily focus on model and hyperparameter selection, AGT succeeds by ensembling multiple models and stacking them in multiple layers. The default behavior of AGT can be summarized as follows: Given a dataset, AGT trains various base models ranging from off-the-shelf boosted trees to customized neural networks on the dataset. The predictions from the base models are used as features to build a stacking model, which learns the appropriate weight of each base model. With these learned weights, the stacking model then combines the base model’s predictions and returns the combined predictions as the final set of predictions.

How Autopilot’s ensemble training mode works

Different datasets have characteristics that are suitable for different algorithms. Given a dataset with unknown characteristics, it’s difficult to know beforehand which algorithms will work best on a dataset. With this in mind, data scientists using AGT often create multiple custom configurations with a subset of algorithms and parameters. They run these configurations on a given dataset to find the best configuration in terms of performance and inference latency.

Autopilot is a low-code ML product that automatically builds the best ML models for your data. In the new ensemble training mode, Autopilot selects an optimal set of AGT configurations and runs multiple trials to return the best model. These trials are run in parallel to evaluate if AGT’s performance can be further improved, in terms of objective metrics or inference latency.

Results observed using OpenML benchmarks

To evaluate the performance improvements, we used OpenML benchmark datasets with sizes varying from 0.5–100 MB and ran 10 AGT trials with different combinations of algorithms and hyperparameter configurations. The tests compared ensemble training mode to HPO mode with 250 trials and HPO mode with 100 trials. The following table compares the overall Autopilot experiment runtime (in minutes) between the two training modes for various dataset sizes.

For comparing performance of multiclass classification problems, we use accuracy, for binary classification problems we use the F1-score, and for regression problems we use R2. The gains in objective metrics are shown in the following tables. We observed that ensemble training mode performed better than HPO training mode (both 100 and 250 trials).

Note that the ensemble mode shows consistent improvement over HPO mode with 250 trials irrespective of dataset size and problem types.

The following table compares accuracy for multi-class classification problems (higher is better).

The following table compares F1 scores for binary classification problems (higher is better).

The following table compares R2 for regression problems (higher is better).

In the next sections, we show how to use the new ensemble training mode in Autopilot to analyze datasets and easily build high-quality ML models.

Dataset overview

We use the Titanic dataset to predict if a given passenger survived or not. This is a binary classification problem. We focus on creating an Autopilot experiment using the new ensemble training mode and compare the results of F1 score and overall runtime with an Autopilot experiment using HPO training mode (100 trials).

The dataset has 890 rows and 12 columns. It contains demographic information about the passengers (age, sex, ticket class, and so on) and the Survived (yes/no) target column.

Prerequisites

Complete the following prerequisite steps:

1. Ensure that you have an AWS account, secure access to log in to the account via the AWS Management Console, and AWS Identity and Access Management (IAM) permissions to use Amazon SageMaker and Amazon Simple Storage Service (Amazon S3) resources.
2. Download the Titanic dataset and upload it to an S3 bucket in your account.
3. Onboard to a SageMaker domain and access Amazon SageMaker Studio to use Autopilot. For instructions, refer Onboard to Amazon SageMaker Domain. If you’re using existing Studio, upgrade to the latest version of Studio to use the new ensemble training mode.

Create an Autopilot experiment with ensemble training mode

When the dataset is ready, you can initialize an Autopilot experiment in Studio. For full instructions, refer to Create an Amazon SageMaker Autopilot experiment. Create an Autopilot experiment by providing an experiment name, the data input, and specifying the target data to predict in the Experiment and data details section. Optionally, you can specify the data spilt ratio and auto creation of the Amazon S3 output location.

For our use case, we provide an experiment name, input Amazon S3 location, and choose Survived as the target. We keep the auto split enabled and override the default output Amazon S3 location.

Next, we specify the training method in the Training method section. You can either let Autopilot select the training mode automatically using Auto based on the dataset size, or select the training mode manually for either ensembling or HPO. The details on each option are as follows:

• Auto – Autopilot automatically chooses either ensembling or HPO mode based on your dataset size. If your dataset is larger than 100 MB, Autopilot chooses HPO, otherwise it chooses ensembling.
• Ensembling – Autopilot uses AutoGluon’s ensembling technique to train several base models and combines their predictions using model stacking into an optimal predictive model.
• Hyperparameter optimization – Autopilot finds the best version of a model by tuning hyperparameters using the Bayesian Optimization technique and running training jobs on your dataset. HPO selects the algorithms most relevant to your dataset and picks the best range of hyperparameters to tune the models.

For our use case, we select Ensembling as our training mode.

After this, we proceed to the Deployment and advanced settings section. Here, we deselect the Auto deploy option. Under Advanced settings, you can specify the type of ML problem that you want to solve. If nothing is provided, Autopilot automatically determines the model based on the data you provide. Because ours is a binary classification problem, we choose Binary classification as our problem type and F1 as our objective metric.

Finally, we review our selections and choose Create experiment.

At this point, it’s safe to leave Studio and return later to check on the result, which you can find on the Experiments menu.

The following screenshot shows the final results of our titanic-ens ensemble training mode Autopilot job.

You can see the multiple trials that have been attempted by the Autopilot in ensemble training mode. Each trial returns the best model from the pool of individual model runs and stacking ensemble model runs.

To explain this a little further, let’s assume Trial 1 considered all eight supported algorithms and used stacking level 2. It will internally create the individual models for each algorithm as well as the weighted ensemble models with stack Level 0, Level 1, and Level 2. However, the output of Trial 1 will be the best model from the pool of models created.

Similarly, let’s consider Trial 2 to have picked up tree based boosting algorithms only. In this case, Trial 2 will internally create three individual models for each of the three algorithms as well as the weighted ensemble models, and return the best model from its run.

The final model returned by a trial may or may not be a weighted ensemble model, but the majority of the trials will most likely return their best weighted ensemble model. Finally, based on the selected objective metric, the best model amongst all the 10 trials will be identified.

In the preceding example, our best model was the one with highest F1 score (our objective metric). Several other useful metrics, including accuracy, balanced accuracy, precision, and recall are also shown. In our environment, the end-to-end runtime for this Autopilot experiment was 10 minutes.

Create an Autopilot experiment with HPO training mode

Now let’s perform all of the aforementioned steps to create a second Autopilot experiment with the HPO training method (default 100 trials). Apart from training method selection, which is now Hyperparameter optimization, everything else stays the same. In HPO mode, you can specify the number of trials by setting Max candidates under Advanced settings for Runtime, but we recommend leaving this to default. Not providing any value in Max candidates will run 100 HPO trials. In our environment, the end-to-end runtime for this Autopilot experiment was 2 hours.

Runtime and performance metric comparison

We see that for our dataset (under 1 MB), not only did ensemble training mode run 12 times faster than HPO training mode (120 minutes to 10 minutes), but it also produced improved F1 scores and other performance metrics.

Inference

Now that we have a winner model, we can either deploy it to an endpoint for real-time inferencing or use batch transforms to make predictions on the unlabeled dataset we downloaded earlier.

Summary

You can run your Autopilot experiments faster without any impact on performance with the new ensemble training mode for datasets less than 100 MB. To get started, create an SageMaker Autopilot experiment on the Studio console and select Ensembling as your training mode, or let Autopilot infer the training mode automatically based on the dataset size. You can refer to the CreateAutoMLJob API reference guide for updates to API, and upgrade to the latest version of Studio to use the new ensemble training mode. For more information on this feature, see Model support, metrics, and validation with Amazon SageMaker Autopilot and to learn more about Autopilot, visit the product page.

About the authors

Janisha Anand is a Senior Product Manager in the SageMaker Low/No Code ML team, which includes SageMaker Autopilot. She enjoys coffee, staying active, and spending time with her family.

Saket Sathe is a Senior Applied Scientist in the SageMaker Autopilot team. He is passionate about building the next generation of machine learning algorithms and systems. Aside from work, he loves to read, cook, slurp ramen, and play badminton.

Abhishek Singh is a Software Engineer for the Autopilot team in AWS. He has 8+ years experience as a software developer, and is passionate about building scalable software solutions that solve customer problems. In his free time, Abhishek likes to stay active by going on hikes or getting involved in pick up soccer games.

Vadim Omeltchenko is a Sr. AI/ML Solutions Architect who is passionate about helping AWS customers innovate in the cloud. His prior IT experience was predominantly on the ground.
